Parts of a roof a ridge board is a horizontal member of the roof frame.

Roof framing plan meaning.

While most home builders will outsource the construction of roofing trusses the rafter supports of the roof itself learning to frame a roof yourself is one of the true arts of carpentry and a basic primer is covered below. Projects that are more complex will include a roof framing plan in both residential and commercial projects. Discover the 36 different types of roofs for a house. Collar ties rafter ties tension beams structural ridge beams.

The point at which all the rafters are attached to. Rafters give the roof its shape and definition. This gallery includes terrific roof design illustrations so you can easily see the differences between types of roofs. A roof framing plan focuses on the structures and supports used to construct the roof and is different from the standard roof plan.

Line length is the hyptenuse of the triangle whose. Conclusions on roof framing. In this type of plan the measurement details of the framing materials are included as well as. As you can see the initial plan for framing your roof needs to take into account several key variables such as the shape of the roof and any relevant community building codes.

Essential advice for owner builders. When working on a roof it pays to be familiar with these terms. Transfers the load of the roof through the raftersto walls. Here is a closer look at common roofing terms.

Roof framing plan what is roof framing plan. You will then have to choose between two very different types of roof framing stick framing vs. A roof framing plan possibly a floor framing plan. The hip or valley rafter forms a diagonal on the roof and the length of that diagonal is 17 for each 12 of run of the common rafters.

If the unit of rise in inches is 3 then the cut is the unit of rise and the unit of run 12 inches or 3 12. This article describes and illustrates the different types of support that prevents roof sagging and wall bulging at buildings including definitions of collar ties rafter ties and structural ridge beams. As you can see in the illustration below roofs have hip rafters ridge boards jack rafters and more. Framing a roof is the last step in framing new construction.

Roof framing involves a lexicon all its own. Here s what you need to know about building codes before you build a house crossframe spacing is another important aspect of developing an economical framing plan. The ridge cut is modified to fit into the space between the common rafters roof types sizing. Figure 2 2 roof framing terms.
